Excitech E5-1224 Heavy-Duty CNC Machining Center

The Excitech E5-1224 Heavy-Duty CNC Machining Center is specifically engineered for solid wood processing, panel furniture manufacturing, and composite material routing where absolute precision and continuous reliability are non-negotiable. Designed around the standard 1220×2440mm panel size, the E5-1224 provides an uncompromising industrial nesting and sizing solution.

Engineered Frame Rigidity & Dynamic Stability

Weighing 2,300 kg, the E5-1224 is built on a normalized, heavy-duty tubular steel base that effectively eliminates harmonic vibration during aggressive cutting cycles. The heavy gantry construction and precision linear guides ensure long-term mechanical accuracy, exceptional contour smoothness, and minimal tool wear even during 24/7 multi-shift operations.

High-Torque Spindle & Motion Control

At the heart of the machine is a high-performance 9/12 kW electro-spindle delivering speeds up to 24,000 RPM. Paired with high-torque industrial servo systems, the machine reaches a rapid traverse speed of 80 m/min and cutting feed rates up to 20 m/min. This raw power allows clean, single-pass nesting in dense hardwoods, MDF, plywood, and abrasive laminates.

Traveling Carousel Auto Tool Changer (ATC)

Tool management is handled via a spindle-mounted 8 / 12 / 16 slot rotary carousel magazine. Because the magazine travels along with the X/Y axes, tool transition cycles are executed directly adjacent to the cutting zone. This design eliminates unnecessary gantry travel to a stationary rear rack, drastically reducing chip-to-chip downtime and maximizing daily throughput.

Multi-Zone Vacuum Matrix & Modular Options

The high-traction grid vacuum table provides uniform suction across partitioned zones, holding small workpieces securely under severe lateral cutting forces. The machine can be configured with optional multi-spindle drilling blocks (9 vertical + 6 horizontal + 1 saw or 5+4 vertical) and specialized right-angle aggregate heads. Complete with a 30 kW electrical setup and a Φ150mm dust extraction manifold, the E5-1224 represents the peak of industrial routing performance.
